C2 Circulating Pump

$82.25

Available Options
C2 12V 27L
  • 12 Volts – 60 Watts – 2.5 Amps
  • Max Flow Rate – 7.1 GPM / 27 LPM
  • Max Temperature – 167 F / 75 C
C2 24V 37L
  • 24 Volts – 60 Watts – 2.5 Amps
  • Max Flow Rate – 9.77 GPM / 37 LPM
  • Max Temperature – 167 F / 75 C
C2 24V 42L
  • 24 Volts – 60 Watts – 2.5 Amps
  • Max Flow Rate – 11 GPM / 42 LPM
  • Max Temperature – 167 F / 75 C
SKU: C1C-1 Categories: , ,

Quantity based pricing table

Description

Specifications of the C2 Circulating Pump:

  • Static psi – 58.0 / 4 Bar
  • Threaded Fittings
  • Inlet / Outlet – 1/2″x 1/2″
  • Maximum Head – 29.52 F / 9 M
  • Max Temperature – 170 F / 75 C

Application of the C2 Circulating Pump:

This is one of our C series micro centrifugal pumps.  This circulating pump is powered by a three-phase brushless DC motor. Our C series pumps are quiet. They are compact and lightweight.  The C2 has a variety of features. It has a seal-less design to prevent leakage. The pump also accepts a wide range of working voltage.  This provides stable performance for the pump.

The C2 is designed for general, commercial and industrial applications. This pump is ideal for all circulation pump purposes. It pumps fresh water and seawater. The C2 can also pump other liquids that are compatible with the pumps materials. The liquids need to be of similar viscosity to water.

Features of the C2 Circulating Pump:

  • Highly efficient ECM three-phase brushless DC motor
  • Sustains a continuous 24-hour workload
  • Life expectancy of well over 20000 hours
  • Advanced magnetic drive technology
  • Sealed rotor-impeller and shaft
  • Leak prevention
  • One moving part: the magnetically driven rotor-impeller
  • Highly precise single ceramic bearing
  • Wear resistant
  • Unique closed impeller
  • Dynamically balanced
  • Strong pressure performance, steady flow
  • Smooth, ultra-quiet operation
  • Protection from stuck impellers
  • Over-voltage and overload protection
  • Over-current protection

Areas of Use of the C2 Circulating Pump:

  • Heating water mattresses
  • Automotive air conditioning
  • Hot water circulating system
  • Electric cars: radiators, heaters
  • Computer CPU cooling circulation
  • Liquid transfer general purpose pumping
  • Fountain, aquariums and larger fish ponds
  • Circulating systems for homes, RV’s and boats
  • Electronics cooling water circulation chiller systems
  • Cleaning equipment, purification and water treatment
